chainflex® control cable CF140.UL

For medium duty applications
Outer jacket:
PVC Overall shield
Flame retardant
Silicone-free
No oil resistance
CFRIP®
chainflex® class: 4.4.1.1

chainflex® control cable CF140.UL

Typical application areas

For medium duty use
Without influence of oil
Preferably indoor applications
Unsupported travel distances and up to 50 m for gliding applications
Wood/stone processing, packaging industry, supply systems, handling, adjusting equipment

Guaranteed lifetime according to guarantee conditions
Double strokes* 5 million 7,5 million 10 million
Temperature, < 10 m ≥ 10 m < 10 m ≥ 10 m < 10 m ≥ 10 m
from/to [°C] R min. [factor x d] R min. [factor x d] R min. [factor x d]
+5 / +15 10 12,5 11 13,5 12 14,5
+15 / +60 7,5 10 8,5 11 9,5 12
+60 / +70 10 12,5 11 13,5 12 14,5
* Higher number of double strokes possible - use the life time calculator on this site

Double strokes*	5 million	7,5 million	10 million
Temperature,	< 10 m	≥ 10 m	< 10 m	≥ 10 m	< 10 m	≥ 10 m
from/to [°C]	R min. [factor x d]	R min. [factor x d]	R min. [factor x d]
+5 / +15	10	12,5	11	13,5	12	14,5
+15 / +60	7,5	10	8,5	11	9,5	12
+60 / +70	10	12,5	11	13,5	12	14,5

Certificates and standards
